| Typical component specifications | |||||||
| Model | PE-120 | PE-240 | PE-500 | PE-1000 | PE-2000 | PE-3000 | PE-4000 |
| Treatment capacity | 0.12T/D | 0.24T/D | 0.5T/D | 1T/D | 2T/D | 3T/D | 4T/D |
| Diaphragm specification | PE-10 | PE-10 | PE-10 | PE-25 | PE-25 | PE-25 | PE-25 |
| Quantity (piece) | 3 | 6 | 13 | 10 | 20 | 30 | 40 |
| Plate thickness | 5 | 8 | 8 | 12 | 15 | 15 | 15 |
| Length*width*height | 300*240*500 | 800*400*600 | 1000*400*600 | 1275*450*800 | 1350*600*1200 | 1850*600*1200 | 2100*700*1200 |
| Remarks | Demonstration equipment | Peripheral strengthening | |||||
| Typical component specifications | ||||||||
| Model | PE-240 | PE-500 | PE-1000 | PE-2000 | PE-3000 | PE-4000 | ||
| Volume of iron oxide tank (L) | 30 | 60 | 108 | 216 | 324 | 427 | ||
| MBR tank volume (L) | 70 | 120 | 216 | 423 | 648 | 854 | ||
| Volume of clear water disinfection tank (L) | 12 | 16 | 25 | 30 | 38 | 44 | ||
| Fan | model | ACO-001 | ACO-003 | ACO-004 | ACO-008 | ACO-012 | ACO-016 | |
| Air volume | 20L/min | 40L/min | 60L/min | 100L/min | 50L/min | 250L/min | ||
| power | 20W | 35W | 35W | 138W | 185W | 390W | ||
| Suction pump | model | DP-50 | DP-50 | DP-75 | DP-200 | DP-300 | DP-400 | |
| flow | 36L/h | 36L/h | 55L/h | 105L/h | 150L/h | 200L/h | ||
| power | 80W | 80W | 130W | 185W | 280W | 300W | ||
| Reflux pump | model | AT-102 | AT-102 | AT-102 | AT-102 | AT-103 | AT-105 | |
| flow | 220L/h | 220L/h | 220L/h | 220L/h | 300L/h | 450L/h | ||
| power | 2W | 2W | 2W | 2W | 0W | 8W | ||
| lift | 0.5m | 0.5m | 0.5m | 0.5m | 0.6m | 1.1m | ||
| blender | 2 | Demonstration equipment | 1 | 1 | 1 | 1 | 1 | |
| 2 | ||||||||
| Membrane module | PE10-6 | PE10-13 | PE25-10 | PE25-20 | PE25-30 | PE25-40 | ||
| Installed power (W) | 105 | 123 | 199 | 337 | 491 | 746 | ||
| Floor area (square) | 0.32 | 0.4 | 0.57 | 0.81 | 1.11 | 1.47 | ||
| Electrical control | Automatic control of liquid level | Automatic control of liquid level | Automatic control of liquid level | Automatic control of liquid level | Automatic control of liquid level | Automatic control of liquid level | ||
